I would like to plug in my outside nest camera to the outside GFCI circuit. It is a weatherproof outlet but I can't get the flaps/holes on the bottom or side to open.

How to do that?

Here is a picture:

enter image description here

Thanks

keshlam
  • 27,539
  • 5
  • 46
  • 94
Gladiator909
  • 69
  • 1
  • 3
  • 3
    You need to consider whether that specific box will remain waterproof after thos knockouts have been knocked out, or if the manufacturer provides gland kits. – Mark Morgan Lloyd Sep 25 '23 at 13:21
  • 4
    @MarkMorganLloyd That box is not waterproof. It's weatherproof. Its purpose is to keep rain /snow /sprinkler water away from the outlet contacts. – JACK Sep 25 '23 at 17:17
  • 2
    With side-cutters: chomp chomp twist. – dandavis Sep 25 '23 at 18:18
  • 1
    @JACK My mistake, /weatherproof/. But the lid has a visible sealing strip around the edge, and any benefit of this will be negated by removing one of those cutouts. – Mark Morgan Lloyd Sep 26 '23 at 06:42
  • @MarkMorganLloyd There's no sealing strip, just a tongue & groove plastic fitting between the box and the lid. Nothing will be negated by removing one or more of the cutouts. This box was designed that way and has UL approval. – JACK Sep 26 '23 at 13:25
  • 1
    @JACK It looked to me as though there was something lighter around the lid, but I barely feel it's worth quibbling about. – Mark Morgan Lloyd Sep 26 '23 at 13:45
  • You could do what they do with these boxes whenever they are installed in any park, beach, street tree, or any other public place: Kick the cover off, kick the box off the wall, leave it dangling from a conduit by its unprotected conductors, and just keep using it that way. Seriously, I don't understand why these plastic boxes are allowed in public places, but that condition seems to be the standard. :) – jay613 Sep 26 '23 at 19:14

4 Answers4

30

Typically a utility knife, a pair of pliers, or both. Cut, then twist, if using both.

The plastic is made thin at the edges to be broken out, but thick enough that the port remains intact until someone decides they actually want it open. They don't slide or otherwise open in a reversible way - they are literally broken out, and the hole will be there forever after.

Stick to using the ones on the bottom as it is mounted, for the least impact on weatherproofing.

Ecnerwal
  • 201,085
  • 10
  • 245
  • 533
  • Some (but not OP's) are reversible, and thus somewhat customizable. I'll add a pic in an answer, although, if you have one of those, it's pretty obvious and you hopefully won't be coming here for an answer :) – jay613 Sep 26 '23 at 19:09
10

If you want this to stay waterproof-ish and the cabling is thin enough, I'd suggest to drill a hole big enough to accommodate a cable gland big enough for the cable and just use cable glands (the plastic screw-on-with-O-ring types) instead of knocking out. Worked like a charm for me. Sometimes you can even get glands that simply match the size of the hole you'd make by doing full knockout instead (i.e. have the same radius), and you can just drill a hole that matches the knockout radius itself and leave the rest of the plastic be.

Alternatively - drill a hole in the knockout, insert the cable and use silicon/epoxy to cover the rest of the hole. If there is no mechanical stress/tension on the cable, and if the hole is placed at the bottom of the box, it will be waterproof enough for most cases.

user213769
  • 201
  • 5
4

In my version of such a box, the cable exit tabs can be yanked out with a pair of pliers, and re-inserted. For things plugged in for days or weeks I like to carve a notch in the bottom one just big enough for the cable and re-insert it.

I do not believe this is possible with OP's box.

enter image description here

jay613
  • 34,254
  • 2
  • 43
  • 136
1

I don't exactly know the name of this, but thanks to a precocious 2-year-old, I noticed that some of these weatherproof receptacles come with a sort of rubber brush cable pass.

enter image description here

You can barely see it on the left side of this picture (and I believe the same cable pass is on the bottom). When you remove the hard plastic you can feed a cable through the rubber brush without completely destroying the weather-proofing (probably best to still only expose the bottom).

It's unclear in your picture if there is a similar rebate for a cable-pass/grommet/gasket but if there is, you could try to find a replacement that fits it for a long-term solution after if/when the plug is removed.
